High Quality Residential Home Stair Lifts for Disabled People and The Elders

Customization: Available
After-sales Service: 24 Hours Technical Support
Warranty: 1 Year

Product Description

Basic Specifications

Model NO.
Stair Lifts
Driving Type
Electric
Capacity
<500kg
Persons
1 People
Speed
Customized
Control Mode
Automatic
Computer Room
No
Deceleration Device
With Deceleration Device
Attendant
Without Attendant
Origin
China
HS Code
8428101001
Production Capacity
10000000 Sets Per Months

Product Overview

High Quality Residential Home Stair Lifts are designed specifically for disabled people and the elderly. A Stair Lift is a battery-operated motorized chair that transports its user up or down a flight of stairs safely. Attached to a track mounted on the staircase, it utilizes a sophisticated rack-pinion drive system to ensure a smooth journey. Built for individuals with limited mobility, it provides an essential solution for maintaining independence in the home.

Our stairlifts maintain and increase your mobility in your own home. No matter whether you use them indoors or outdoors, or have a straight, curved, or spiral staircase - we have the right solution for you. These systems are engineered with the latest safety and innovation technology.

Main Parameters

Product Name Leather Curved Seat PU Curved Stair Lift Linear Seat Elevator
Transfer MethodRack and Pinion(Grease)Rack and Pinion(Grease)Rack and Pinion(Grease)
DriverDC Motor DriveDC Motor DriveDC Motor Drive
Power350W350W350W
Energy Consumption0.014kwh0.014kwh0.014kwh
BatteryTwo 12V9Ah lead-acidTwo 12V9Ah lead-acidTwo 12V9Ah lead-acid
Speed0.12m/s0.12m/s0.12m/s
Seat TypeSwivel SeatSwivel SeatSwivel Seat
Track MaterialSteel PipeSteel PipeAluminum Alloy
Standard Load120KG120KG120KG
Max Load160KG160KG140KG

Core Features & Benefits

01 The latest advanced control technology
02 Double tube rail with 0-52 degree flexibility
03 Space-saving foldable armrests and footrests
04 Innovative swivel seat design for easy access
05 Ergonomic joystick for intuitive operation
06 Electronic self-locking safety belt
07 Seven-layer comprehensive safety system
08 LCD status and diagnostic display screen
09 High-sensitivity safety sensors
10 Overspeed mechanical braking system
11 Intelligent wireless call service system
12 Integrated battery management system

Intelligent Safety & Control

Overspeed Safety Protection: Our self-developed system is patented for innovation. If the lift exceeds the pre-set safety speed, the machine immediately cuts power and engages a mechanical brake to guarantee absolute user safety.

Intelligent Call System: The long-distance remote control features both jog and linkage functions. Users can control the stair lift to automatically move up or down, making it exceptionally simple for users with limited dexterity.

Frequently Asked Questions

How is the stair lift powered?
The stair lift is powered by a high-efficiency DC motor driven by two 12V9Ah lead-acid batteries, ensuring operation even during power outages.
What is the weight capacity?
The standard maximum load is 120KG, with heavyweight options available that support up to 160KG.
Can it be installed on curved stairs?
Yes, we provide specialized curved stair lifts that use a double tube rail system capable of handling angles from 0 to 52 degrees.
What safety features are included?
The system includes a seven-layer safety protection system, sensitive safety sensors, an overspeed brake, and an electronic self-locking seat belt.
How does the charging work?
The lift features automatic charging at both ends of the track. Intermediate charging positions can also be added for longer staircases.
What is the warranty period?
The standard warranty period for our stair lift systems is 12 months.
